Manufacturer

     ALU+ limited

Type

• Continuous louvre system with a pitch of 34mm.
• All profiles are manufactured from aluminium extrusions.
• Z-shaped louvre blades.
•  Can be fitted to an existing construction and is supported by vertical mullions.

Material

• Aluminium - all parts (mullions, clips and blades) are manufactured from aluminium extrusions Al Mg Si 0,5 (6063 T6)
• Profile thickness: minimum 1.0 mm.

Finish :

• Natural anodised15-22micron
• Polyester powder coated - BS6496
• Powder coating in any RAL or B/S colour available
• Thickness of powder coating 40 micron minimum

Protection :

• Fibre glass insect mesh fitted as standard.
• Other meshes available as an option
• A reinforcement profile carrying extra blade supports is fitted when the width of the louvre is > 700mm.

Manufacture

• Aluminium blade profiles are clipped into aluminium blade support clips.
• The blade pitch is 34mm & the visual free area is 64%.

Assembly

Custom made by our skilled Craftsmen to your exact requirements
